This cable stripping machine is specially designed for stripping inner conductors of sheathed cables, it's also suitable for stripping normal electric wires, it can process several wires at one time with high efficiency.
We offer various models for your option,
such as hot knife type, heavy-duty model, twisting function, as well as special function customer request.
Parameter description:
Cut: The machine is equipped with a set of cutters and a set of strippers. The cutters automatically cut the wire ends, and then use the strippers to strip the wires.
Twist: With the core wire twisting function, the copper wires inside are automatically twisted together after stripping.
Delay: With the stripping delay function, you can set how long the blade will delay after cutting through the wire skin before pulling back to strip the wire.
Hot knife: The knife has a heating function, mainly for wires that require special hot stripping.
Model Wire diameter Function Net Weight Dimension Φ0.2~2mm cut 12kg 330*190*270mm Φ0.2~1.5mm twist 13kg 330*240*290mm twist+cut 15kg 330*190*270mm twist+delay 13kg 330*420*290mm twist+cut+delay 15kg 330*190*270mm Φ0.2~2.5mm hot knife stripping 13kg 300*200*280mm Φ0.2~3mm cut 15kg 330*240*330mm cut+delay 15kg Φ0.2~2mm twist 14kg 330*190*345mm twist+cut 15kg twist+delay 14kg twist+cut+delay 15kg Φ0.5~5mm cut 20kg 330*240*340mm Φ0.5~8mm cut 21kg 330*240*400mm
Stripping length: 0~25mm (customizable)
Air pressure: 0.5~0.7Mpa
Working voltage: 220V 50/60Hz
Note：
The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.
Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
