Insulated Ring Terminal

  • Model：RVN5.5-4L-90D-P
  • Net. Weight：
  • Dimension：
Online Inquiry
Item No
Cable Size A.W.GThickness(mm)
Max Current
USA Screw
Screw Dia.d2(mm)
Dimension（mm)Color
W L E DФ
RVN 1.25-3-90D
0.5-1.5（22-16）0.7519A#43.25.718.510.54.0Red
RVN 1.25-3.5S-90D#63.75.718.5
RVN 1.25-3.5M-90D#63.76.620.0
RVN 1.25-3.5L-90D#63.78.021.5
RVN 1.25-4S-90D#84.36.620.1
RVN 1.25-4L-90D#84.38.021.5
RVN 1.25-5S-90D#105.38.0
21.5
RVN 1.25-5L-90D#105.39.823.5
RVN 1.25-6S-90D1/46.49.823.0
RVN 1.25-6L-90D1/46.411.627.5
RVN 1.25-8-90D5/168.411.627.5
RVN 1.25-10-90D3/810.513.631.0
Item No.
Cable Size A.W.GThickness(mm)
Max Current
USA Screw
Screw Dia.d2(mm)
Dimension（mm)Color
W L E DФ
RVN 2-3-90D
1.5-2.5（16-14）0.827A#43.26.61810.54.6Blue
RVN 2-3.5S-90D#63.76.618
RVN 2-3.5M-90D#63.76.620.1
RVN 2-3.5L-90D#63.78.521.8
RVN 2-4S-90D#84.36.620.1
RVN 2-4L-90D#84.38.522.4
RVN 2-5S-90D#105.38.5
22.4
RVN 2-5L-90D#105.39.522.4
RVN 2-6S-90D1/46.49.522.4
RVN 2-6L-90D1/46.412.027.5
RVN 2-8-90D5/168.412.027.5
RVN 2-10-90D3/810.514.631.5
Item No
Cable Size A.W.GThickness(mm)
Max Current
USA Screw
Screw Dia.d2(mm)
Dimension（mm)Color
W L E DФ
RVN 3.5-4-90D
2.5-4.0（14-12）1.037A#84.38.026.414.26.5Black
RVN 3.5-5S-90D
#105.38.026.4
RVN 3.5-5L-90D
#105.312.029
RVN 3.5-6-90D
1/46.412.029
RVN 3.5-8-90D
5/168.415.035.5
RVN 3.5-10-90D
3/810.515.035.5
Item No
Cable Size A.W.GThickness
Max Current
USA Screw
Screw Dia.d2(mm)
Dimension（mm)Color
W L E DФ
RVN 5.5-3-90D
4-6（12-10）1.048A#43.27.224.314.27Yellow
RVN 5.5-3.5-90D
#63.77.224.3
RVN 5.5-4S-90D
#84.37.224
RVN 5.5-4L-90D
#84.39.527.2
RVN 5.5-5-90D
#105.39.527
RVN 5.5-6-90D
1/46.412.031
RVN 5.5-8-90D
5/168.415.035.5
RVN 5.5-10-90D
3/810.515.036
