Power Cord Plug Injection Moulding Machine

  • Model：KS-J85C
  • Net. Weight：3500kg
  • Dimension：2900×1300×3000mm
Online Inquiry

This is a power plug injection molding machine, suitable for injection molding of power plugs, data cables, USB, audio cables, chargers, connectors and other products. The injection mold needs to be customized according to the product, and the quantity that can be injected at a time depends on the size of the product.

It is suitable for various thermoplastics: PVC, TPR, TPE, PE, PBT, PC, PS, PP, PU, PA, POM, PMMA, PET, PPO, PPS, ABS, LCP, acrylic, melamine, nylon , polypropylene, polystyrene, etc.

KINGSING

Download: (1)
Screw DiameterΦ38mmΦ45mmΦ50mm
Injection Pressure173Mpa (1760kgf/cm2)122Mpa (1254kgf/cm2)100Mpa (1016kgf/cm2)
Theoretical Injection Volume181cm3254cm3314cm3
Max. Injection Weight168g (5.9oz)236g (8.3oz)
292g (10.3oz)
Injection Rate125cm3/s175cm3/s217cm3/s
Injection Speed111mm/s

Screw Ration Speed: 0~240rpm

Clamping Force: 85ton (833KN)

Clamping Stroke: 270mm

Min. Mould Thickness: 185mm

Max. Opening: 455mm

Max. Mould Size: 500*350mm

Ejector Distance: 90mm

Ejector Force: 2.7Ton (26.5KN)

System Pressure: 13.7Mpa (140kgf/cm)

Oil Tank Capacity: 350L

Motor Power: 15KW (20HP)

Heater Power: 10.2KW

Net. Weight: 3500kg

Dimension: 2900×1300×3000mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
