Enamelled Wire Stripper

  • Model：KS-E516
  • Wire Size：
  • Net. Weight：
  • Dimension：
Online Inquiry

The machine adopts imported alloy material, durable and easy maintenance.

  1. Special stripping blades design make the waste material easy to clean.

  2. Easy to install and adjust, the machine has a protection cover,very considerable design.

  3. This machine can strip enameled wire which is not very straight,stripping is fast and clean.

  4. This machine can process different size of enameled wire without change the blade.

Suitable Wire Diameter: 0.4 ~ 5.0mm
Stripping Length: 2 ~ 90mm
Power Rating: 120W
Motor Rotate Speed: 2800r/min
Power Supply: 220V/50Hz
Net Weight: 6.8Kg
Dimension: 280 x 200 x 150mm

Note：

  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
