Excellent price/performance ratio;
Easy to program and operate, the operator can get started quickly without any training;
Designed by human structural mechanics to reduce fatigue strength;
Adjustable stripping parameters and customized different sizes of guiding tubes;
lt adopts hot stamp marking method to mark on the wire surface, the temperature can be adjusted through the controller;
Equipped with HMl control system, the stripping and printing parameters can be set in the touch screen;
The feeding and cutting mechanisms are all driven by servo motors, the processing accuracy is higher than that of common step motor；
This machine can do cutting, full stripping and half stripping. The stripping mode can be freely set. For example, it is possible to perform two-head full stripping or half-stripping, one head full-stripping and one head half-stripping, only stripping head not stripping tail;
If the wire cutting length is larger than 800mm, long wire conveyor belt can be optional, the length of the belt is customized.
Available Wire Diameter: Ф0.1~10mm2
Drive Mode: 4-roller drive
Max.Cutting Length: 100000mm
Rated Power: 1KW
Speed: 800 pcs/hour (depending on the wire length and mark number)
Stripping Length: Head:0~35mm, End:0~35mm
Stripping Accuracy: ±(0.002mm×stripping length)
Cutting Accuracy: ±(0.002mm×cutting length)
Memory Function: Unlimited
Display: LCD display with English menu
Temp. Adjusting Range: 60°C~180°C
Character Size: 1.0~2.4mm(Customized)
Number of Characters: 7~50(Customized)
Operation Temperature: 0~40°C
Environment Humidity: 30%~80%RH (No condensation at 40°C)
Power Supply: Standard AC220V 50/60Hz
Air Pressure: 0.5~0.7Mpa (Stable, clean and dry air source )
Conveyor Belt: 1.5m(Customized)
Net Weight: Main Machine: 164KG, Conveyor Belt:57KG
Dimension (L*W*H): Main Machine: 1150*660*1220mm
Conveyor Belt: 1750*680*1000mm
