GPH90 Copper Tube Terminals

GPH90 Copper Tube Terminals

GPH90 Copper Tube Terminals

GPH90 Copper Tube Terminals

GPH90 Copper Tube Terminals

Model：GPH90-35/8
Net. Weight：
Dimension：

Online Inquiry

PartNo.	Dimension（mm)
PartNo.	ФE	ФD	Фd	W	B	L
GPH90-6/5	5.3	6.5	3.5	10	14	22.5
GPH90-6/6	6.4	6.5	3.5	12	14	24
GPH90-6/8	8.5	6.5	3.5	15	14	27.5
GPH90-6/10	10.5	6.5	3.5	16	14	29.5
GPH90-10/5	5.3	7	4.5	12	16	23
GPH90-10/6	6.4	7	4.5	12	16	24
GPH90-10/8	8.5	7	4.5	15	16	28
GPH90-10/10	10.5	7	4.5	18	16	29.5
GPH90-16/5	5.3	8.5	5.5	12	20	22.5
GPH90-16/6	6.4	8.5	5.5	14	20	24
GPH90-16/8	8.5	8.5	5.5	15	20	28
GPH90-16/10	10.5	8.5	5.5	18	20	31
GPH90-16/12	13	8.5	5.5	19	20	32
GPH90-25/6	6.4	10	6.9	15	21	27.5
GPH90-25/8	8.4	10	6.9	16	21	32.5
GPH90-25/10	10.5	10	6.9	18	21	32.5
GPH90-25/12	13	10	6.9	19	21	34
GPH90-35/6	6.4	12	8.5	17	24	28.5
GPH90-35/8	8.5	12	8.5	17	24	34
GPH90-35/10	10.5	12	8.5	20	24	34
GPH90-35/12	13	12	8.5	22	24	40.5
GPH90-50/6	6.4	14	10	20	28.5	37
GPH90-50/8	8.4	14	10	20	28.5	40.5
GPH90-50/10	10.5	14	10	20	28.5	40.5
GPH90-50/12	13	14	10	23	28.5	42.5
GPH90-50/16	17	14	10	28	28.5	50.5
GPH90-70/8	8.5	16.5	12	24	31	43
GPH90-70/10	10.5	16.5	12	24	31	43
GPH90-70/12	13	16.5	12	24	31	44.5
GPH90-70/16	17	16.5	12	28	31	53
GPH90-70/20	21	16.5	12	30	31	59
GPH90-95/8	8.5	18	13.5	26	35	44.5
GPH90-95/10	10.5	18	13.5	26	35	44.5
GPH90-95/12	13	18	13.5	26	35	46.5
GPH90-95/16	17	18	13.5	28	35	52
GPH90-95/20	21	18	13.5	30.5	35	59
GPH90-120/10	10.5	19.5	15	29	35.5	49
GPH90-120/12	13	19.5	15	29	35.5	49
GPH90-120/16	17	19.5	15	29	35.5	55
GPH90-120/20	21	19.5	15	30.5	35.5	61
GPH90-150/10	10.5	21	16.5	31	40	48
GPH90-150/12	13	21	16.5	31	40	51
GPH90-150/16	17	21	16.5	31	40	56
GPH90-150/20	21	21	16.5	34	40	61.5
