  4. Terminal Connector

Non-Insulated Ring Terminal

  • Model：RNB 1.25-4L
  • Net. Weight：
  • Dimension：
Online Inquiry
Item No Cable Size AWGThickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Color
W L F EWsH
RNB 1.5-3
 0.5-1.5(22~16)0.75 19A #4 3.2 5.712.65.04.84.1
4.0
RNB 1.5-3.5S
 #63.75.712.65.0
RNB 1.5-3.5M
 #63.76.614.46.3
RNB 1.5-3.5L
 #63.78.015.87.0
RNB 1.25-4S
 #8 4.36.614.46.3
RNB 1.25-4L
 #8 4.38.015.87.0
RNB 1.25-5S
 #105.38.015.87.0
RNB 1.25-5L
 #105.39.817.48.0
RNB 1.25-6S
1/46.49.817.68.0
RNB 1.25-6L
1/46.411.621.811.1
RNB 1.25-8
5/168.411.621.811.1
RNB 1.25-10
3/810.513.625.514
Item No Cable Size AWGThickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)）Color
W L F EWsH
RNB 2-3
 1.5-2.5(16~14)0.8 27A #4 3.26.612.54.34.85.0
5.0
RNB 2-3.5S
 #63.76.612.54.5
RNB 2-3.5M
 #63.76.614.56.5
RNB 2-3.5L
 #63.78.516.87.7
RNB 2-4S
 #8 4.36.614.26.5
RNB 2-4L
 #8 4.38.516.87.7
RNB 2-5S
 #105.38.516.87.7
RNB 2-5L
 #105.39.516.87.7
RNB 2-6S
1/46.49.516.87.7
RNB 2-6L
1/46.412.021.811.0
RNB 2-8
5/168.412.021.811.0
RNB 2-10
3/810.514.626.014
Item No Cable Size AWGThickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Color
W L F EWsH
RNB 3.5-4
 2.5-4.0(14~10)1.0 37A #84.38.018.07.76.07.05.8
RNB 3.5-5S
 #105.38.0

18.0

7.7
RNB 3.5-5L
 #105.312.021.49.3
RNB 3.5-6
1/46.412.021.49.3
RNB 3.5-8
5/168.415.027.113.6
RNB 3.5-10
3/810.515.027.113.6
Item No Cable Size AWGThickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)尺寸
W L F EWsH
RNB 5.5-3
 4.0-6.0(12~10)1.0 48A #4 3.27.216.26.76.28.06.6
RNB 5.5-3.5S
 #63.77.216.26.7
RNB 5.5-4S
 #84.37.216.26.7
RNB 5.5-4L
 #8 4.39.519.08.5
RNB 5.5-5
 #105.39.519.08.5
RNB 5.5-6
1/46.412.023.011.0
RNB 5.5-8
5/168.415.027.513.7
RNB 5.5-10
3/810.515.027.513.7
RNB 5.5-12
1/2 1319.232.416
Item No Cable Size AWGThickness(mm)Max CurrentUSA ScrewScrew Dia.d2(mm)Color
W L F EWsH
RNB 8-4
 6.0-10(8)1.2 62A #84.38.823.8118.58.38.8
RNB 8-4L
 #84.312.023.89.3
RNB 8-5S
 #105.38.823.811
RNB 8-5M
 #105.312.023.89.3
RNB 8-5L
 #105.315.029.829.5
RNB 8-6S
1/46.412.023.89.3
RNB 8-6L
1/46.415.029.829.5
RNB 8-8
5/168.415.029.829.5
RNB 8-10
3/810.515.029.829.5

Terminal Body：Copper

Plating：Tin
